|Topic Review (Newest First)|
|03-16-2013 08:58 PM|
Originally Posted by hverma View Post
only one model(2.4watts) out of the regular 1/8 npt port 2 way solenoid, is below 4watts.
currently have them(2.4watts) on the selling units.
low power consumption stainless steel Humphrey model exist, but not available on their website or on any PDF, they are the special order.
I was lucky to obtain some of these special Humphrey stainless steel solenoids, I believe they were used in tech trade show, then liquidated after the show.
it is in the picture, wasn't ready to give the name so I masked it, but now all of you know it is a Humphrey stainless steel solenoid.
|03-16-2013 02:37 PM|
|hverma||Humphrey makes solid, reliable, heavy duty solenoids which can be used in our applications (haven't used them, but the spec sheets look good).|
|03-14-2013 04:39 AM|
|03-14-2013 04:22 AM|
Save one for me?
It sure is a nice mini solenoid valve.
I forgot to add on 3 more solenoid with low watts, but they're mostly panel mount and in-line, not that great in my opinion.
|03-14-2013 04:14 AM|
Originally Posted by Bettatail View Post
|03-14-2013 04:09 AM|
|03-14-2013 04:00 AM|
|FlyingHellFish||Yeah, those AK 47 regulators are a beau.|
|03-14-2013 03:57 AM|
nice solenoids and low power consumption, and actually the SMC VQ100 series pneumatic circuit solenoid, it is the lowest power consumption miniature type, I try to build a aluminum manifold but fail, not be able to achieve the precision on metal working, aluminum is not good to drill or tap, not like brass.
other SMC miniature, so bad there is no 1/8 npt port version and a clippard mouse solenoid mounted type is not be able to find.
|03-14-2013 03:36 AM|
Originally Posted by Bettatail View Post
Who would do such a thing Not sure if that was towards me, I don't even sell. Did someone hog the burket solenoids? I totally miss that deal.
|03-14-2013 02:37 AM|
Originally Posted by kevmo911 View Post
they all work on a clippard 15490 manifold.
and clippard is the only source provide single manifold that for $5 a piece, shipping and handling charge is not friendly though.
|03-14-2013 02:07 AM|
Thanks for the info, Betta. I haven't tested the MAC valves beyond reg and metering valve tests, during which they had no issues.
Interesting that you posted a pic of a Mouse and Numatics valve on the Clippard mount. You can really see the diameter difference. I assume they both work on that mount - is that a correct assumption?
Also interesting that the Gems are re-branded.
Hellfish, I tried to get my machinist friend to make me a bunch of SS Mouse mounts. Unfortunately, we've been drifting apart, though he still has my Mouse and mount, and I still have his promise to make me some. But it's been over a year now, so I'm not holding my breath. Might be worth looking into making a bunch of mounts. My friend told me a while back that the going rate was $30something/hour for just labor.
One other link - I've been using one of these on a Concoa 212 for a few months with no problems. It's a 4W SS CKD. Gets hot, but not too hot. Only problem is it's 1/8 BSPT ports, so you need two NPT/BSPT adapters and 1 BSPT plug. Probably $15-20 shipped from Grainger for 304 SS. And $21 shipped for the solenoid.
As far as the MAC valve availability, there are 8 or 10 workable listings on the US 'bay, many of which have multiple units.
|03-14-2013 01:39 AM|
here is a good one, mask the name of the solenoid because I don't want to give out info before I can talk to the seller to see if he has more and lists them for sale individually(not "lot"), so everyone builds their own pressurized system has a fair chance to get one.
it is a stainless steel solenoid that can rival the Burkert 2822.
|03-14-2013 12:53 AM|
For such a small request, I'm surprise they don't make the thing. The Gem is in-line and 70 dollar per unit with a min of 10. I check the other solenoids, unfortunately none of them stand out and are high watts. Davis Control (distributor) is trying to find me another option, very nice of them especially for just one person.
The Mac looks good, but I'm just so keen on getting these manifold. Would a custom order of a manifold be logical? I remember Swagelok had a poster saying something along the lines of "if you can dream it", "we can make it" or something.
What if we get the dimensions of the solenoids from their respective pdf, go to a shop and get them to drill the 1/8 holes.
PS - Couldn't find anything on the MAC, fleabay is weird sometimes. The clippard mouse always seem to show up and there is usually a very good deal on them. I seen lot of 5 for 30 bucks, shipping kills it for me though.
|03-14-2013 12:50 AM|
Clippard mouse, Numatics, Gems(re-branded), ASCO, and a couple more(not list here), are miniature or have miniature models, 10-32 manifold mounted type solenoids, these solenoids are slow flow rate and low power consumption, really good choice to use for our pressurized co2 system.
here is an old picture of the clippard mouse solenoid and the Numatics miniature stainless steel solenoid, on the clippard manifold.
and the burkert stainless steel type 200 solenoid is on the left.
|03-14-2013 12:39 AM|
Kevin, show the public what to get only if you are 100% sure it works and works well.
Gems solneoid is something else, it is re-branded other brand, I don't want to give more info here because for a 10-32 mounted type solenoid, clippard mouse is the way to go.
Numatics valve corporation owns ASCO, I believe, but they are independent operated.
Mac 35 series solenoid, 2.4 watts or lower power consumption model sure can be found on evil bay, but I don't recommend it because this type of solenoid has a top relieve port, the gas can be relieve through this relief port.
what cause the problem is when the solenoid gets old, the internal seal has problem to stop leaking through relieve port once the solenoid is at power on position.
I bought, and tested them, actually the solenoids mentioned in fryinghellfish and kevmo911 previous posts, I do have them, and have more brands, models that no one has any clue. I only show what to get only if I am sure they work, work well, and there is plenty to get when the time that large quantity of certain models show up on evil bay.
so far the clippard mouse mounted type solenoid, the burkert 2822, burkert 200 series and 300 series, numatics mounted type, and some others, are positively confirmed that work well, and I've been showing these models are ok to use in numerous threads, as well as showing hobbyists where to get them publicly or through Pms.
I don't give out other solenoid information because if there is no large quantity in a fair way everyone has a chance to grab, some people will take advantage of the info and act evil(grab them all on evil bay), I believe some people know what I am talking about here.
I don't against anyone who do their own research, and grab all the solenoids or metering valves that they feel suitable from ebay, but act like vultures taking advantage of others research efforts, not good.
